OMB Control No.: 2127-0004 Part 573 Safety Recall Report 23V-698 The information contained in this report was submitted pursuant to 49 CFR §573 Manufacturer Name : Ferrari North America, Inc. Submission Date : OCT 17, 2023 NHTSA Recall No. : 23V-698 Manufacturer Recall No. : RC 86 Manufacturer Information : Manufacturer Name : Ferrari North America, Inc. Address : 250 Sylvan Avenue Englewood Cliffs NJ 07632-2500 Company phone : 1800-999-9999 Population : Number of potentially involved : 614 Estimated percentage with defect : 100 % Vehicle Information : Vehicle 1 : 2022-2024 Ferrari SF90 Vehicle Type : LIGHT VEHICLES Body Style : 2-DOOR Power Train : HYBRID ELECTRIC Descriptive Information : Ferrari has determined that a defect related to motor vehicle safety may exist in some MY2022 – MY2024 Ferrari SF90 vehicles. The issue relates to a potential issue regarding the turbocharger oil delivery pipe due to a notch detected on its external surface and reduced thickness, which make the pipe not conforming to Ferrari technical drawing requirements. Ferrari has had no reports of any fires, oil leaks, other incidents and/or deaths as a consequence of this issue. Affected vehicles: MY2022 – MY2024 Ferrari SF90 Stradale; MY2022 – MY2024 Ferrari SF90 Spider. Production Dates : NOV 07, 2022 – SEP 19, 2023 VIN Range 1 : Begin : ZFF96NMA2N0286206 End : ZFF96NMA9R0299931 ✔ Not sequential Description of Defect : Description of the Defect : Ferrari has determined that a defect related to motor vehicle safety may arise in some MY2022 – MY2024 Ferrari SF90 vehicles. The issue relates to a potential issue regarding the turbocharger oil delivery pipe due to a notch detected on its external surface and reduced thickness, which make the pipe nonconforming to Ferrari technical drawing requirements. FMVSS 1 : NR FMVSS 2 : NR Description of the Safety Risk : The defect may cause potential oil leakage. Oil leakage in the presence of an ignition source increases the risk of fire. Description of the Cause : Nonconformity of the turbocharger oil delivery pipes with the Ferrari technical drawing requirements, as the pipes have been found with a notch on their external surface and reduced thickness. Part 573 Safety Recall Report 23V-698 Page 2 The information contained in this report was submitted pursuant to 49 CFR §573 Identification of Any Warning that can Occur : Oil pressure warning light and a display of vehicle limited performance message appear on vehicle’s dashboard. Involved Components : Component Name 1 : turbocharger oil delivery pipe Component Description : turbocharger oil delivery pipe Component Part Number : 925718 Component Name 2 : turbocharger oil delivery pipe Component Description : turbocharger oil delivery pipe Component Part Number : 923390 Supplier Identification : Component Manufacturer Name : T.ERRE Srl Address : Via Armaroli, 9 Calderara di Reno Foreign States 40012 Country : Italy Chronology : During preproduction review of a new vehicle in July 2023, Ferrari identified a potential issue regarding the turbocharger oil delivery pipe (which is also fitted on the SF90 model vehicle). In particular, the oil pressure warning light appeared in the instrument panel, along with the display of a message of limited engine performance. Oil leakage was also noticed. Ferrari immediately began an investigation of the issue and initially detected a notch on the oil delivery pipe, also in July 2023. After further investigations carried out between August and September 2023, an additional defect was found on the same oil delivery pipe related to its thickness, which did not conform with the specifications indicated in Ferrari’s technical drawing. Based on production records, it was found that the potentially affected parts were installed in vehicles manufactured between November 2022 and September 2023. Ferrari immediately instructed the supplier to take corrective measures in order to deliver parts conforming with Ferrari technical drawing requirements, while Ferrari’s investigations continued. On October 10, 2023, Ferrari concluded its investigations after relevant testing did not show any failure replicating the condition observed in the preproduction vehicle. However, as a precautionary measure, on October 12, 2023, Ferrari decided to launch a recall campaign to remedy this Part 573 Safety Recall Report 23V-698 Page 3 The information contained in this report was submitted pursuant to 49 CFR §573 potential issue and notify NHTSA accordingly. For the recall, Ferrari shall replace the nonconforming turbocharger oil delivery pipes with conforming ones. Ferrari determined that no warranty claims have been submitted for this issue. Furthermore, Ferrari has had no reports of any fires, incidents and/or deaths as a consequence of this issue. Description of Remedy : Description of Remedy Program : The repair consists of replacing the nonconforming turbocharger oil delivery pipes installed on the SF90 model with new conforming ones. Ferrari will send a notice letter to all affected vehicle owners to warn them of this issue, and instruct them 1) to contact an authorized Ferrari dealer to schedule the free recall repair, and 2) in the meantime, request them not to use the vehicles. How Remedy Component Differs from Recalled Component : The new turbocharger oil delivery pipes will conform to Ferrari technical drawing requirements, without notches on the external surface and with the appropriate thickness. Identify How/When Recall Condition was Corrected in Production : All SF90 vehicles currently in production have been fitted with conforming turbocharger oil delivery pipes starting from September 20, 2023. Recall Schedule : Description of Recall Schedule : A notification letter will be sent to all known current owners of the affected vehicles advising them to contact an authorized Ferrari dealer to schedule an appointment to have the recall work performed and, in the meantime, requesting them not to use the vehicles. The letters are scheduled to be sent on or before December 16, 2023. Planned Dealer Notification Date : OCT 17, 2023 – NR Planned Owner Notification Date : DEC 16, 2023 – NR * NR – Not Reported

**************************************************************************************************************

URGENT! MANDATORY STOP-SALE NOTICE Distribution list: Dealer Principal; General Manager; Sales Manager; and Service Manager Date: October 17, 2023 Effective immediately, a MANDATORY STOP-SALE is in effect for: ALL MY2022 – MY2024 SF90 Stradale and MY2022 – MY2024 SF90 Spider Vehicles Issue: Ferrari has determined that a defect related to motor vehicle safety may arise in some MY2022 – MY2024 SF90 Stradale and MY2022 – MY2024 SF90 Spider vehicles. The issue relates to a potential issue regarding the turbocharger oil delivery pipe due to a notch detected on its external surface and reduced thickness, which make the pipe not conforming to Ferrari technical drawing requirements. Ferrari decided to launch a recall campaign to remedy this potential issue and has notified NHTSA. Ferrari is working on a repair to address this issue; at this time a repair is not available. Further information regarding the recall and availability of the spare parts necessary to perform the repair will be provided in the coming days. Required Dealer Action:  Effective immediately and until further notice, ALL MY2022 – MY2024 SF90 Stradale and MY2022 – MY2024 SF90 Spider vehicles are on mandatory stop-sale hold.  DO NOT sell, offer for sale or lease, or allow demo/test drives of any of the subject MY2022 – MY2024 SF90 Stradale and MY2022 – MY2024 SF90 Spider vehicles.  In the interest of customer safety and satisfaction, place all MY2022 – MY2024 SF90 Stradale and MY2022 – MY2024 SF90 Spider vehicles at your dealership in a secure area where they cannot be made available for sale, lease, trade or demonstrator use until a repair to address this issue is made available and has been performed. IMPORTANT REMINDER: VEHICLES AFFECTED BY SAFETY & COMPLIANCE RECALLS New Vehicles in Dealer Inventory: It is a violation of federal law for a dealer to deliver a new motor vehicle or any new or used item of motor vehicle equipment (including a tire) covered by this notification under a sale or lease until the defect or noncompliance is remedied. By law, dealers must correct, prior to delivery for sale or lease, any vehicle that fails to comply with an applicable Federal Motor Vehicle Safety Standard or that contains a defect relating to motor vehicle safety. Pre-Owned Vehicles in Dealer Inventory: Dealers should not deliver any pre-owned vehicles in their inventory which are involved in a safety or compliance recall until the defect has been remedied.

**************************************************************************************************************

Ferrari North America, Inc. Technical Department TI-3049 USA RECALL CAMPAIGN REF. NO. C24000086 REPLACEMENT OF ENGINE TURBOCHARGER LUBRICATION SYSTEM DELIVERY PIPES MODEL YEARS 2022 – 2024 October 2023 READ, INITIAL, AND PASS ON » Service Manager Parts Manager Service Writer Technician Warranty Clerk Technical Instructions (cont.) 2 Ferrari North America, Inc. Technical Department TI-3049 October 2023 Dear Authorized Ferrari Dealer: Ferrari has decided that a defect which relates to motor vehicle safety exists in certain Ferrari vehicles listed below. The vehicles involved were manufactured from assembly 208041 to assembly 220434: SF90 Stradale 2022 – 2024 VIN No. 286206 to VIN No. 299931 SF90 Spider This recall involves the replacement of the LH and RH turbocharger lubrication system delivery pipes which is necessary due to a possible non-conformity of these components which may cause an oil leak resulting in potential fire. IMPORTANT Ferrari will be notifying ALL affected vehicle owners nationwide with a letter indicating that the vehicle must be brought in immediately and the replacement parts will be installed free of charge. Owners may contact Ferrari North America at (201) 816-2668; Ferrari’s campaign number for this recall is C24000086. You must order the necessary part for each vehicle. Upon completion of the repair, we will reimburse you for the parts and labor necessary to perform this campaign under the normal warranty system. It is a violation of Federal law for a dealer to deliver a new motor vehicle covered by this notification under a sale or lease until the recall campaign is completed. Also, dealers should not deliver any pre-owned vehicles in their inventory which are involved in a safety or compliance recall until the defect has been remedied. Technical Department Ferrari North America, Inc. Technical Instructions (cont.) 3 Ferrari North America, Inc. Technical Department TI-3049 U.S.A. RECALL CAMPAIGN NO. C24000086 MODEL YEARS 2022 – 2024 REPLACEMENT OF ENGINE TURBOCHARGER LUBRICATION SYSTEM DELIVERY PIPES RECALL CAMPAIGN OVERVIEW SUBJECT: Recall Campaign No. C24000086 VEHICLES: Ferrari models in question were manufactured from assembly 208041 to assembly 220434: SF90 Stradale 2022 – 2024 VIN No. 286206 to VIN No. 299931 SF90 Spider See Modis for VINs involved. CONDITION: The vehicles involved require the replacement of the LH and RH turbocharger lubrication system delivery pipes, which is necessary due to a possible non-conformity of these components which may cause an oil leak resulting in a potential fire. The list of the vehicles involved can be viewed directly from the New Modis portal by selecting the menu “Recall and Service Campaign Management” and entering the campaign number indicated (New Modis / Service / Campaigns / CMP-Campaigns -> C24000086). REMEDY: Ferrari will repair the vehicle free of charge. The repair involves the replacement of the LH and RH turbocharger lubrication system delivery pipes. Technical Instructions (cont.) 4 Ferrari North America, Inc. Technical Department TI-3049 RECALL CAMPAIGN OVERVIEW (cont.) PARTS INVOLVED: The parts necessary to implement this RECALL CAMPAIGN are listed below and need to be ordered from the Parts Department. Part Number Description Qty. 70007937 OIL DELIVERY PIPE KIT 1 Update the CRM customer database in Modis accordingly as soon as you receive any notification regarding the status of the vehicle (e.g., change of ownership, etc.). The list of vehicles involved in the update is viewable on the New Modis site, using the “Recall and Service Campaign Management” function, entering the campaign number indicated below. SERVICES UNDER WARRANTY: A refund for the costs incurred by the implementation of the RECALL CAMPAIGN in question shall be made immediately after a Warranty Claim has been received by the Technical Service Department. The Warranty Claim must include the following information: SF90 Stradale / SF90 Spider › Campaign number ……………………………………………………………………………………………………………………….. 86 › Cost code ………………………………………………………………………………………………………………………………………… 24 › Malfunction code ………………………………………………………………………………………………………. 7309000403 › Problem code ………………………………………………………………………………………………………………………………… 01 › Labor code ………………………………………………………………………………………………………………. 73090004030 › Time allowance ……………………………………………………………………………………………………………… 6.05 hours REIMBURSEMENT: Upon receipt of a Warranty Claim via Modis. The activities described in this Recall Booklet must be performed as soon as possible with the utmost urgency. Technical Instructions (cont.) 5 Ferrari North America, Inc. Technical Department TI-3049 U.S.A. RECALL CAMPAIGN NO. C24000086 MODEL YEARS 2022 – 2024 REPLACEMENT OF ENGINE TURBOCHARGER LUBRICATION SYSTEM DELIVERY PIPES TECHNICAL INSTRUCTIONS Please read all instructions before performing this campaign. Procedure To perform the repair work, you must order the following parts from the Parts Department: Description Part No. Quantity OIL DELIVERY PIPE KIT 70007937 1 Replacement of LH turbocharger oil delivery pipe  Drain the engine cooling system.  Drain the engine lubrication system.  Remove the rear flat undertray section.  Remove the engine air intake system filter box.  Remove the LH engine air intake system filter box.  Remove the A/C system compressor.  Loosen the collar – Fig.1 Technical Instructions (cont.) 6 Ferrari North America, Inc. Technical Department TI-3049  Disconnect and remove the duct – Fig. 2. Fig. 1 Fig. 2 Technical Instructions (cont.) 7 Ferrari North America, Inc. Technical Department TI-3049  Unscrew the screw – Fig. 3.  Place a used liquid container underneath the work area and unscrew the screw – Fig. 4. Fig. 3 Fig. 4 Technical Instructions (cont.) 8 Ferrari North America, Inc. Technical Department TI-3049  Disconnect the turbocharger oil delivery pipe – Fig. 5.  Unscrew the screws – Fig. 6. Fig. 5 Fig. 6 Technical Instructions (cont.) 9 Ferrari North America, Inc. Technical Department TI-3049  Unscrew the screws – Fig. 7.  Unscrew the screws – Fig. 8. Fig. 7 Fig. 8 Technical Instructions (cont.) 10 Ferrari North America, Inc. Technical Department TI-3049  Place a drain pan underneath the work area and unscrew the connecting pipe.  Disconnect the water return pipe – Fig. 10. Fig. 9 Fig. 10 Technical Instructions (cont.) 11 Ferrari North America, Inc. Technical Department TI-3049  Place a drain pan underneath the work area and unscrew the oil delivery pipe union. Disconnect and remove the LH turbocharger oil delivery pipe – Fig. 11.  Take the new LH turbocharger oil delivery pipe and check that the respective gaskets are not damaged and correctly fitted – Fig. 12. Fig. 11 Fig. 12 Technical Instructions (cont.) 12 Ferrari North America, Inc. Technical Department TI-3049  Fit and connect the LH turbocharger oil delivery pipe. Partially tighten the pipe union – Fig. 13.  Partially tighten the screw – Fig. 14. Fig. 13 Fig. 14 Technical Instructions (cont.) 13 Ferrari North America, Inc. Technical Department TI-3049  Partially tighten the screw – Fig. 15.  Tighten the turbocharger oil delivery pipe union to a torque of 14 Nm. Tighten the pipe union by giving the wrench another quarter turn – Fig. 16. Fig. 15 Fig. 16 Technical Instructions (cont.) 14 Ferrari North America, Inc. Technical Department TI-3049  Connect the LH turbocharger water return pipe by replacing the respective gasket – Fig. 17.  Replace the turbocharger water return pipe union gasket and tighten the pipe union to a torque of 25 Nm – Fig. 18. Fig. 18 Fig. 17 Technical Instructions (cont.) 15 Ferrari North America, Inc. Technical Department TI-3049  Tighten the screw fastening the water return pipe to the turbocharger to a torque of 10 Nm – Fig. 19.  Tighten the screw fastening the oil delivery pipe to the turbocharger to a torque of 10 Nm – Fig. 20. Fig. 19 Fig. 20 Technical Instructions (cont.) 16 Ferrari North America, Inc. Technical Department TI-3049  Tighten the screw fastening the oil delivery pipe to the turbocharger to a torque of 10 Nm – Fig. 21.  Connect the oil delivery pipe – Fig. 22. Fig. 21 Fig. 22 Technical Instructions (cont.) 17 Ferrari North America, Inc. Technical Department TI-3049  Tighten the screw fastening the oil delivery pipe to the engine to a torque of 10 Nm – Fig. 23.  Tighten the screw fastening the water delivery pipe to the oil delivery pipe to a torque of 10 Nm – Fig. 24. Fig. 23 Fig. 24 Technical Instructions (cont.) 18 Ferrari North America, Inc. Technical Department TI-3049  Fit and connect the duct – Fig. 25.  Tighten the screw collar fastening the air filter box hose to the turbocharger – Fig. 26. Fig. 25 Fig. 26 Technical Instructions (cont.) 19 Ferrari North America, Inc. Technical Department TI-3049  Refit the A/C system compressor.  Refit the engine air intake system filter box.  Refit the LH engine air intake system filter box.  Fill the engine cooling system.  Fill the engine lubrication system.  Check the turbocharger pipe connections for leaks.  Refit the rear flat undertray section.  Road test the vehicle.  Remove the rear flat undertray section.  Check the turbocharger pipe connections for leaks.  Refit the rear flat undertray section. Technical Instructions (cont.) 20 Ferrari North America, Inc. Technical Department TI-3049 Replacement of RH turbocharger oil delivery pipe  Remove the RH engine air intake system filter box.  Undo the indicated screws – Fig. 27.  Unscrew the screw – Fig. 28 Fig. 27 Fig. 28 Technical Instructions (cont.) 21 Ferrari North America, Inc. Technical Department TI-3049  Remove the heat shield – Fig. 29  Unscrew the screws – Fig. 30 Fig. 29 Fig. 30 Technical Instructions (cont.) 22 Ferrari North America, Inc. Technical Department TI-3049  Unscrew the screws – Fig. 31  Place a drain pan underneath the work area. Disconnect and remove the engine lubrication system oil delivery pipe – Fig. 32 Fig. 31 Fig. 32 Technical Instructions (cont.) 23 Ferrari North America, Inc. Technical Department TI-3049  Unscrew the indicated screws – Fig. 33 and 34 Fig. 33 Fig. 34 Technical Instructions (cont.) 24 Ferrari North America, Inc. Technical Department TI-3049  Place a drain pan underneath the work area. Disconnect and remove the engine lubrication system oil return pipe – Fig. 35  Undo the indicated screw – Fig. 36. Fig. 35 Fig. 36 Technical Instructions (cont.) 25 Ferrari North America, Inc. Technical Department TI-3049  Place a drain pan underneath the work area and unscrew the screw – Fig. 37  Disconnect the turbocharger oil delivery pipe – Fig. 38 Fig. 37 Fig. 38 Technical Instructions (cont.) 26 Ferrari North America, Inc. Technical Department TI-3049  Place a drain pan underneath the work area. Disconnect and remove the turbocharger oil delivery pipe – Fig. 39  Take the new RH turbocharger oil delivery pipe and check that the respective gaskets are not damaged and correctly fitted – Fig. 40. Fig. 39 Fig. 40 Technical Instructions (cont.) 27 Ferrari North America, Inc. Technical Department TI-3049  Fit and connect the RH turbocharger oil delivery pipe. Partially tighten the pipe union – Fig. 41.  Connect the oil delivery pipe – Fig. 42 Fig. 41 Fig. 42 Technical Instructions (cont.) 28 Ferrari North America, Inc. Technical Department TI-3049  Partially tighten the screw – Fig. 43  Tighten the turbocharger oil delivery pipe union to a torque of 14 Nm. Tighten the pipe union by giving the wrench another quarter turn – Fig. 44 Fig. 43 Fig. 44 Technical Instructions (cont.) 29 Ferrari North America, Inc. Technical Department TI-3049  Tighten the screw fastening the oil delivery pipe to the engine to a torque of 10 Nm – Fig. 45.  Tighten the screw fastening the water delivery pipe and oil delivery pipe to the engine to a torque of 10 Nm – Fig. 46. Fig. 45 Fig. 46 Technical Instructions (cont.) 30 Ferrari North America, Inc. Technical Department TI-3049  Replace the engine lubrication system oil return pipe gaskets. Fit the engine lubrication system oil return pipe – Fig. 47  Tighten the screws fastening the oil return pipe to the engine oil tank to a torque of 10 Nm – Fig. 48. Fig. 47 Fig. 48 Technical Instructions (cont.) 31 Ferrari North America, Inc. Technical Department TI-3049  Tighten the screws fastening the oil return pipe to the engine to a torque of 10 Nm – Fig. 49.  Replace the engine lubrication system oil delivery pipe gaskets. Fit the engine lubrication system oil delivery pipe – Fig. 50 Fig. 49 Fig. 50 Technical Instructions (cont.) 32 Ferrari North America, Inc. Technical Department TI-3049  Tighten the screws fastening the oil delivery pipe to the engine to a torque of 10 Nm – Fig. 51.  Tighten the screws fastening the oil delivery pipe to the engine oil tank to a torque of 10 Nm – Fig. 52. Fig. 51 Fig. 52 Technical Instructions (cont.) 33 Ferrari North America, Inc. Technical Department TI-3049  Fit the heat shield – Fig. 53  Tighten the screw fastening the heat shield to the rear subframe to a torque of 7 Nm – Fig. 54. Fig. 53 Fig. 54 Technical Instructions (cont.) 34 Ferrari North America, Inc. Technical Department TI-3049  Tighten the screws fastening the heat shield to the rear subframe – Fig. 55  Refit the RH engine air intake system filter box.  Fill the engine lubrication system.  Check the turbocharger pipe connections for leaks.  Refit the rear flat undertray section.  Road test the vehicle.  Remove the rear flat undertray section.  Check the turbocharger pipe connections for leaks.  Refit the rear flat undertray section. Thank you for your co-operation. Please do not hesitate to contact us with any further queries. Fig. 55

**************************************************************************************************************

**************************************************************************************************************
