January 9, 2020 NHTSA CAMPAIGN NUMBER: 20V007000
Passenger Air Bag Inflators May Explode
An inflator explosion may result in sharp metal fragments striking the driver or other occupants resulting in serious injury or death.
NHTSA Campaign Number: 20V007
Manufacturer Ferrari North America, Inc.
Components AIR BAGS
Potential Number of Units Affected 982
Summary
Ferrari North America, Inc. (Ferrari) is recalling certain 2009-2011 California and 2010-2011 458 Italia vehicles equipped with non-desiccated, passenger frontal air bag inflators containing phase stabilized ammonium nitrate (PSAN) propellant that were used as interim remedy parts for previous Takata recalls. These inflators may explode due to propellant degradation occurring after long-term exposure to high absolute humidity, high temperatures, and high temperature cycling.
Remedy
Ferrari will notify owners, and dealers will replace the front passenger air bag assembly with an alternate one, including a new non-ammonium nitrate inflator, free of charge. The recall began March 8, 2020. Owners may contact Ferrari customer service at 1-201-816-2668. Ferrari’s number for this recall is 60FL.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.
Check if your Ferrari has a Recall
Ferrari North America Technical Information
Date: March 2020
Bulletin#: FNA 170
Campaign#: 24100060
Supersedes:
Section:
Model and Model Year:
2009, 2010, 2011 California
2010, 2011 458 Italia
Subject : Recall 60A 24100060 Extension
In 2016, Ferrari launched the first Takata Recall 60 ( 24000060), which included MY 2009-2011 California and 2010-2011 458 Italia Ferrari Vehicles.
With recall 24000060, the passenger side airbag of the vehicles involved, had to be replaced with a “like for like” part. This means that the airbags were substituted wit h an identical air bag, but newer, and therefore not presenting the issues caused by time and exposure to humid environments.
Once the final remedy parts became available in 201 7 , Recall 60A ( 24100060) has been launched , replacing the Recall 24000060.
With Recall 24100060, the passenger side airbag had to be replaced with the final remedy part 70004993.
All the vehicles that have already had the like for like replacement were excluded by Recall 24100060, in order to give priority to the most critical vehicles.
NHTSA has now required the affected manufacturers to recall all the vehicles that have had the like for like replacement , in order to replace it with the final remedy part 70004993.
FNA will extend Recall 24100060 for all the vehicles that need to have the like for like passenger side airbag replaced with the final remedy airbag
Attached you can find the bullet in for the recall 60 A ( 24 10006 0 ) final remedy (where the prioritization by Zone has to be disregarded), and below the list of the 672 VINs included in the extension of recall 24100060.
USA
RECALL CAMPAIGN
REF. NO. 60
TAKATA PASSENGER FRONTAL
AIR BAG MODULE
MODEL YEARS 2010- 2011
MODEL YEARS 2009 – 2011
OCTOBER 2017
READ , INITIAL AND PASS ON »
Ferrari North America, Inc.
October 2017
Dear Ferrari Dealer:
Ferrari has decided that a defect which relates to motor vehicle safety exists in certain Model Year 2009-2011 Ferrari California and Model Year 2010-2011 458 Italia vehicles equipped with a passenger-side front air bag manufactured and supplied by Takata Corporation. We want to assure you that our clients’ safety is our priority, and we are committed to correcting this condition in their vehicles.
Takata has reported that the passenger side front air bag inflator could potentially rupture in vehicles involved in an incident in which the frontal airbags deploy. This risk is due to propellant degradation which may occur after long-term exposure to high temperatures, high absolute humidity and high temperature cycling causing the inflator to rupture in deployment, which may result in serious injury or death to vehicle occupants.
Ferrari is now able to provide a “FINAL REMEDY” repair to the above referenced vehicles and will no longer be permitting the use of “like-for-like” passenger side airbag replacements.
IMPORTANT
The National Highway Traffic Safety Administration (NHTSA) and the impacted vehicle manufacturers, including Ferrari, are prioritizing Takata air bag repairs to ensure that vehicles with air bags that pose a higher risk to safety are fixed first while simultaneously working to ensure that parts are available to repair every affected vehicle as quickly as possible.
NHTSA has decided to prioritize the recall based on three geographical zones.
Zone A States are: Alabama, California, Florida, Georgia, Hawaii, Louisiana, Mississippi, South Carolina, Texas, Puerto Rico, American Samoa, Guam, the Northern Mariana Islands (Saipan), and the U.S. Virgin Islands
Zone B States are: Arizona, Arkansas, Delaware, District of Columbia, Illinois, Indiana, Kansas, Kentucky, Maryland, Missouri, Nebraska, Nevada, New Jersey, New Mexico, North Carolina, Ohio, Oklahoma, Pennsylvania, Tennessee, Virginia, and West Virginia,
Zone C States are: Alaska, Colorado, Connecticut, Idaho, Iowa, Maine, Massachusetts, Michigan, Minnesota, Montana, New Hampshire, New York, North Dakota, Oregon, Rhode Island, South Dakota, Utah, Vermont, Washington, Wisconsin, and Wyoming
Customers in Zone A that have not had Recall 60 (i.e., the ‘like-for-like’ repair) performed will be the first to have this recall performed. Ferrari will notify the Zone A owners with a letter indicating that the parts are available, and will replace the passenger side air bag module, free of charge.
Please note that this is the FINAL REMEDY version of the passenger frontal airbag for these models.
Owners may contact Ferrari North America at (201) 816-2668. Ferrari’s number for this recall is 60.
It is a violation of Federal law for a dealer to deliver a new motor vehicle covered by this notification under a sale or lease until the defect is remedied.
An initial supply of the final remedy airbags will be sent to you by the FNA Parts Department. You must however order the necessary brackets and hardware required for each vehicle. Any additional airbags required can be ordered directly from the FNA Parts Department.
Upon transmittal of the repair under the normal warranty system, we will reimburse you for the labor necessary to carry out this campaign.
Technical Department
Ferrari North America, Inc.
Ferrari North America, Inc. Takata Passenger Airbag Module (ZA)
SECOND NOTICE – URGENT SAFETY RECALL
This notice applies to your vehicle (VIN: ZFFXXXXXXXXXXXXXX).
RC 60 / NHTSA 16V-341
Dear [Mr. John Doe],
This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act.
Ferrari has decided that a defect which relates to motor vehicle safety exists in certain Model Year 2009-2011 California and Model Year 2010-2011 458 Italia vehicles equipped with a passenger-side front airbag manufactured and supplied by Takata Corporation. We want to assure you that your safety is our priority, and we are committed to correcting this condition in your vehicle.
Takata has reported that the passenger side front airbag could potentially rupture in vehicles involved in an incident in which the frontal airbags deploy. This risk is due to propellant degradation which may occur after long-term exposure to high temperatures, high absolute humidity and high temperature cycling causing the inflator to rupture in deployment. Metal fragments may pass through the airbag striking vehicle occupants, leading to serious injury or death.
Our records show that your vehicle has not yet received the free repair.
IMPORTANT – CONTACT YOUR DEALER TODAY
The National Highway Traffic Safety Administration (NHTSA) and the impacted vehicle manufacturers, including Ferrari, are prioritizing Takata airbag repairs to ensure that vehicles with airbags that pose a higher risk to safety are fixed first while simultaneously working to ensure that parts are available to repair every affected vehicle as quickly as possible. Based on NHTSA’s criteria, your vehicle has been selected for this recall.
Final replacement airbags are now available in your area. Please make an appointment with your nearest dealer to have the FREE repair performed on your vehicle.
Ferrari will repair your vehicle free of charge. The repair involves replacing the Passenger Frontal Airbag Module. Please contact your Ferrari dealer at that time and make an appointment to have this repair performed. The time needed for this repair is estimated to be between 2 and 5 hours depending on the model; however, your dealer may need to keep your vehicle for a longer period of time. Please be prepared to leave your vehicle with your dealer for at least a full day.
Please also note that only the passenger frontal airbag is affected by this recall. The driver’s frontal airbag is unaffected.
If you have any questions or concerns that your dealer is unable to resolve, please contact Ferrari North America, Inc. at +1 (201) 816-2668 or NHTSA at +1(888) 327-4236.
Thank you for your attention to this important matter.
Technical Department Ferrari North America, Inc.
PLEASE NOTE: Federal law requires that any vehicle lessor receiving this recall notice must forward a copy of this notice to the lessee by First Class Mail within ten business days.
U.S.A. RECALL CAMPAIGN NO. 60
Model Years 2010 – 2011
Model Years 2009 – 2011
Takata Passenger Frontal Air Bag
RECALL CAMPAIGN OVERVIEW
| INTRODUCTION: | Ferrari 458Italia and Ferrari California Vehicles |
| SUBJECT: | Recall Campaign No. 60 |
| VEHICLES: | Ferrari 458Italia, MY 2010 – 2011 Ferrari California, MY 2009 – 2011 (see ModisCS for VINs involved) |
| CONDITION: | These vehicles are equipped with air bag inflators assembled as part of the passenger frontal air bag modules, used as original equipment or replacement equipment. In the event of a crash necessitating passenger frontal air bag deployment, these inflators may rupture due to propellant degradation occurring after long-term exposure to absolute humidity and temperature cycling. An inflator rupture may result in metal fragments striking the vehicle occupants resulting in serious injury or death. |
| REMEDY: | Ferrari will repair the vehicle free of charge. The repair involves replacing the Passenger Air Bag Module. This repair takes approximately 2 to 5 hours to complete depending on the model. |
RECALL CAMPAIGN OVERVIEW (cont.)
PARTS INVOLVED: The parts necessary to implement the RECALL CAMPAIGN are described herein and an initial supply will be provided to you directly from FNA. After which you will need to order any additional airbags you require.
|
P/N 70004993 | Qty. 1 | |
|
P/N 761617 | Qty. 1 | |
|
P/N 802804 | Qty. 1 | |
|
|||
|
P/N 012643701 | Qty. 4 | |
|
P/N 010902028 | Qty. 4 | |
|
P/N 000102741 | Qty. 4 | |
|
P/N 012643701 | Qty. 4 | |
Update the CRM customer database on the ModisCS website accordingly as soon as you receive any notification regarding the status of the vehicle (e.g., change of ownership, scrapping, etc.).
Services under warranty
Ferrari California Vehicles
|
60 |
|
24 |
|
49.7.00.001 |
|
01 |
|
49.0.90.308.0 |
|
5.00 Hours |
RECALL CAMPAIGN OVERVIEW (cont.)
458 Italia vehicles
|
60 |
|
24 |
|
7.00.001 |
|
01 |
|
0.90.308.1 |
|
1.35 Hours |
REIMBURSEMENT : Upon receipt of a warranty claim via ModisCS
U.S.A. RECALL CAMPAIGN No. 60
Model Years 2010 – 2011
Model Years 2009 – 2011
Takata Passenger Frontal Air Bag and Brackets
TECHNICAL INSTRUCTIONS
Please read all instructions before performing this campaign.
The procedure required for this RECALL CAM PAIGN consists in replacing the Passenger Side Air Bag module .
| – IMPORTANT – |
| After completing the necessary procedure, you must enter the serial number of the a irbag in the service entry as per FNA 151 |
| – IMPORTANT – |
|
The RECALL CAMPAIGN procedure described herein must be performed precisely as indicated by the following instructions:
| – IMPORTANT – |
| NOT damage the packaging of the new replacement airbag since it must be reused to hold the airbag that has been removed from the vehicle. |
| – IMPORTANT – |
| The fixing nuts of the passenger airbag module to the dashboard and the fixing screws and washers of the relative retention bracket to the airbag itself, must be replaced and installed as they were originally; see the relative table in the Parts Catalog. |
| – IMPORTANT – |
| Protect the steering wheel adequately during the procedures to remove trim elements described as follows. |
1. Replacing the passenger side airbag module
1.1 Remove the la be l with the airbag identification details, shown in Fig. 1, from the new airbag and affix it in the relative space in a printout of the “Passenger side airbag module replacement traceability form”, included in this booklet.
1.2 Disconnect the battery (as described in paragraph F01 of the Workshop Manual).
1.3 Remove the passenger side airbag mod u le (as described in paragraph F4.02 step 3 of the 458 Italia Workshop Manual) .
NOTE: For the Ferrari California model, the updated procedure is available from the July 2016 update of the Technical Documentation.
| – IMPORTANT – |
| The nuts that fasten the passenger airbag module to the dashboard trim and the screws and washers that fasten the retainer bracket to the airbag must be replaced and installed as they were originally; see the relative table in the Spare Parts Catalo . |
1.4 The installation of the new airbag module P/ N 70004993 requires the use of a special bracket to mount the airbag to the dashboard. See the Overview section of this booklet for the bracket part numbers as well as the hardware part
The new component is marked with a specific label bearing the phrase ” PAB- FER- F1 64 SP” on the packaging, as seen in Fig. 1 .
Install the NEW passenger side airbag module and bracket (as described in paragraph F4.0 2 step 3 of the 458 Italia Workshop Manual).
NOTE: For the Ferrari California mod el, the updated procedure is available from the July 2016 update of the Technical Documentation.
| – IMPORTANT – |
| The airbag module fastener screws must be tightened with a calibrated and certified torque wrench to the torque specified in the relative chapter of the Workshop Manual. |
1.5 Reconnect the battery (as described in paragraph F2.01 of the Workshop Manual).
1.6 Turn the ignition switch to KEY-ON and check that there are no indicator lamps or warnings relative to the airbag or any other systems on the instrument cluster.
1.7 Connect the DEIS diagnostic tester to the diagnostic socket in the vehicle and perform the airbag control unit cycle 10 NAB Complete Cycle.
1.8 Ensure that the cycle is completed successfully – Fig. 2.
1.9 Access the ” OTC” a rea of the DEIS
Tester relative to the “NAB” airbag ECU, select “Save” , ” Preview ” and ” Print ” in the sequence given and check that there are no active errors in the ECU memory – Fig. 3 .
Note: If any errors are stored, open an ROL with the description “Technical Support” , attaching the file generated.
1.10 At the end of the procedure, perform a SCAN OUT with the DEIS tester .
1.11 Complete the form “Passenger side airbag module replacement traceability form”, included in this booklet , in full, and attach it to the warranty claim
2. Guidelines for returning replaced airbag modules
2.1 Replaced airbag modules and UN-USED ” Like-for- Like” airbag modules will be collected from your premises by Takata or by personnel appointed by Ta ka ta. The guidelines which must be observed for correctly returning these components are given below:
2.2 The dealer must contact Takata by writing to the e-mail address Business Services @eu.takata.com, or by calling the Call Center (phone number: +49 (0)6021 65 2222), providing the general details and information necessary for collection of the components.
2.3 Takata / the courier will prepare the necessary shipping documents .
2.4 The Takata center sends the ADR document (document for the transport of dangerous goods) to the dealer , which will then be handed to the shipping company together with the Do Not Sign the ADR document unless you are officially certified to ship dangerous goods and have the required 24 hour hotline.
2.5 The dealer must ensure that the packaging containing the replaced airbag module is sealed correctly (use the same packaging in which the replacement airbag module was received).
| – IMPORTANT – |
| DO NOT damage the packaging of the new replacement airbag, as it must be reused to ship the airbag removed from the vehicle. |
| – IMPORTANT – |
| DO NOT rip or tear off the labeling on the container. |
Ferrari North America, Inc.
Takata Passenger Airbag Module
RC 60FL / NHTSA 20V-007
This notice applies to your vehicle (VIN)
Dear,
This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act.
Ferrari has decided that a defect which relates to motor vehicle safety exists in certain Model Year 2009-2011 458 Italia and California vehicles equipped with a passenger-side front airbag manufactured and supplied by Takata Corporation. We want to assure you that your safety is our priority, and we are committed to correcting this condition in your vehicle.
The passenger side front airbag could explode if your vehicle is involved in a crash in which the frontal airbags deploy. This risk is due to propellant degradation which may occur after long-term exposure to high temperatures, high absolute humidity and high temperature cycling causing the inflator to explode in deployment. Sharp metal fragments may pass through the airbag striking vehicle passengers, leading to serious injury or death.
We understand that this vehicle previously received an interim repair. Ferrari is now recalling this interim part to replace it with the final repair that uses a different propellant to inflate the airbag.
Our records show that you are the owner of a vehicle affected by this recall.
IMPORTANT – CONTACT YOUR DEALER TODAY FOR YOUR FREE REPAIR
FINAL replacement airbags are now available in your area. Please make an appointment with your nearest dealer to have the FREE repair performed on your vehicle.
Ferrari will repair your vehicle FREE of charge. The repair involves replacing the Passenger Frontal Airbag Module. Please contact your Ferrari dealer at this time and make an appointment to have this repair performed. The time needed for this repair is estimated to be between 2 and 5 hours depending on the model; however, your dealer may need to keep your vehicle for a longer period of time. Please be prepared to leave your vehicle with your dealer for at least a full day.
Please also note that only the passenger frontal airbag is affected by this recall. The driver’s frontal airbag is unaffected.
If you have any questions or concerns that your dealer is unable to resolve, please contact Ferrari North America, Inc. at +1(201) 816-2668. If your Dealer or Ferrari is unable to remedy the defect without charge or within a reasonable amount of time, you may submit a complaint to the Administrator, National Highway Traffic Safety Administration, 1200 New Jersey Ave., S.E., Washington, DC 20590, call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY: 1-800-4249153), or go to https://www.safercar.gov
Thank you for your attention to this important matter.
Technical Department Ferrari North America, Inc.
5 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| FERRARI | 458 ITALIA | 2010-2011 |
| FERRARI | CALIFORNIA | 2009-2011 |
9 Associated Documents
Recall Quarterly Report #1, 2020-1
RCLQRT-20V007-6892.PDF 211.14KB
Loading...
Reload document
Open in new tab
Recall 573 Report – Amendment 1
RCLRPT-20V007-2504.PDF 215.289KB
Loading...
ISSUED Owner Notification Letter(Part 577)
RCONL-20V007-6464.pdf 229.919KB
Loading...
Recall 573 Report – Amendment 2
RCLRPT-20V007-4594.PDF 215.305KB
Loading...
Defect Notice 573 Report
RCLRPT-20V007-6026.PDF 215.282KB
Loading...
Recall Acknowledgement
RCAK-20V007-6574.pdf 325.397KB
Loading...
Recall Quarterly Report #2, 2020-2
RCLQRT-20V007-0736.PDF 211.245KB
Loading...
Remedy Instructions and TSB – Redacted to remove PII
RCRIT-20V007-5183.pdf 3344.356KB
Loading...
Recall Quarterly Report #3, 2020-3
RCLQRT-20V007-8776.PDF 211.326KB
Loading...
Latest Recalls Documents
For the Latest and Most Recent Recalls Information Visit the link below…
https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=20V007&docType=RCL
1 Associated Investigation
Air Bag Inflator Rupture
NHTSA ID: EA15001
Dated opened: February 24, 2015
The Office of Defects Investigation (ODI) opened PE14-016 in June 2014 based on six inflator rupture incidents involving consumer owned vehicles produced by five vehicle manufacturers. All six vehicles were operated in Florida or Puerto Rico at the time of the rupture and for the majority of their service life, and were equipped with inflators produced by Takata, a tier-one supplier of automotive air bag systems.
During the course of PE14-016, ODI determined that five additional vehicle manufacturers used inflators of a similar design and vintage also supplied by Takata. No evidence of field failures was found in vehicles produced by these five additional manufacturers. Nonetheless, at ODI’s insistence, all 10 vehicle manufacturers initiated a regional recall within approximately two weeks of the opening of the investigation. The regions recalled initially included Florida, Puerto Rico, Hawaii, and the U.S. Virgin Islands, areas with high absolute humidity and climatic conditions believed to be a significant factor in the inflator ruptures. As part of the recall actions, inflators removed from remedied vehicles are to be returned to Takata for testing.
Takata’s initial test results on passenger inflators from remedied vehicles indicated a much higher than anticipated rupture frequency for inflators returned from Florida. Accordingly ODI requested all 10 manufacturers expand the regional recalls for passenger inflators to include other geographic areas where high absolute humidity conditions exist, including the Gulf States and other coastal areas. Takata’s testing of the passenger inflators to date continues to indicate this geographic area as having the highest risk, with no ruptures occurring from inflators returned from outside the expanded recall regions. During PE14-016 four additional passenger inflator field events occurred, all in vehicles from the same expanded geographic region.
Also during PE14-016 four additional driver inflator field events occurred including two in vehicles from regions not known for high absolute humidity, specifically California and North Carolina. Accordingly, ODI requested all five of the affected vehicle manufacturers currently using the subject Takata driver inflators expand to nationwide recalls. Significantly, neither of the affected vehicle manufacturers or Takata provided any explanation to account for these two driver air bag inflator ruptures outside the area of high absolute humidity. Takata testing of returned driver inflators indicates a lower rupture frequency as compared to passenger inflator testing. All test ruptures reported by Takata to date have occurred on inflators returned from high absolute humidity areas.
The investigation now includes all manufacturers and vehicles known to be affected at this time. ODI’s investigation will focus on, among other things, root cause analysis, other potential defect consequences, identification of affected vehicles scope, and adequacy of the remedy.
The five ODI reports cited above can be reviewed online at https://www-odi.nhtsa.dot.gov/owners/SearchNHTSAID under the following identification numbers: 10537899, 10568848, 10585224, 10605877, 10651492
- 🎄【Easy to Use--Work out of box】+【FOXWELL 2024 New Version】 FOXWELL NT604 Elite scan tool is the 2024 new version from FOXWELL, which is designed for those car owners who want to figure out the cause issue before fixing the car problem via scanning the most common systems like abs srs engine and transmission.The NT604 Elite diagnostic tool comes with latest software, which can be used out of box. No need to waste time to download the software first.
- 🎅【Affordable】+【Reliable Car Health Monitor】 Will you be confused what happen when the warning light of abs/srs/transmission/check engine flashes? Instead of taking your cars to dealership, this foxwell scanner will help you do a thorough scanning and detection for your cars and pinpoint the root cause. It will t-urn off the warning light car after the problem is fixed.👉TIPS: Airbag crash/collision data can NOT be cleared even you replace the new airbag.
- 🎄【5 in 1 Diagnostic Scanner】Compared with those auto scanners (50-100), NT604 Elite code scanner not only includes their OBDII diagnosis but also it can be an abs/srs scanner, transmission and check engine code reader. When it’s an odb2 scanner, you can use it to check if your car is ready for annual test through I/M readiness menu. In addition, live data stream, built-in DTC library, data play back and print, all these features are a big plus for it.
- 🎅【Fantastic AUTOVIN】+【No extra software fee】Through the AUTOVIN menu, this NT604 Elite car scanner allows you to get your V-IN and vehicle info rapidly, no need to take time to find your V-IN and input one by one. What's more, the NT604 Elite abs srs scanner supports 60+ car makes from worldwide (America/Asia/Europe). You don’t need to pay extra software fee.
- 🎄【Solid protective case KO plastic carrying bag】+ 【Lifetime update】Almost all same price-level obd scanner diagnostic tool only offers plastic bag to hold on the scanner.However, NT604 Elite automotive scanner is equipped with solid protective case, preventing your obd2 scanner from damage. Then you don’t need to pay extra money to buy a solid toolbox.
- 5 IN 1 DIAGNOSTIC SCANNER: This is an OBDII scanner and 4 systems diagnostic tool. The AUTOPHIX 3210 PRO Bluetooth Auto Scanner not only has OBDII diagnostic function, but can also be used as an ABS/SRS/transmission scanner and check engine code reader. When it is an OBD2 scanner, you can use it to check if your car is ready for annual test via I/M preparation menu. In addition, the built-in DTC library, live data stream, data playback, performance testing and many more such functions are supported by it.
- RELIABLE CAR HEALTH MONITOR: Are you confused when the ABS/SRS/Transmission/Check Engine warning light is blinking? The AUTOPHIX 3210 PRO Bluetooth Scanner will help you to do a thorough scanning and inspecting of your car and find out the root cause, which saves your time and money. Tip:The warning light will be turned off after the problem is solved. Airbag crash/collision data cannot be cleared, even if you replace the airbag with a new one.
- QUICK DIAGNOSIS: The 3210 PRO is the newest 2024 Enhanced 4-System Bluetooth Code Reader that retrieves vehicle information, reads/clears trouble codes, and displays a 4-in-1 live data stream. You'll easily find out what's wrong with your car. In just a few minutes, you'll be in control of your car!
- EXCLUSIVE APP: Are you tired of the following with third party apps? For example: 1.need to download different apps for different cars? 2. require extra download fees? 3. only support a few functions? 4. can only use one of Android and iOS? Now!One AUTOPHIX 3210 PRO Scanner is enough to solve all the above problems. The must-have wireless/bluetooth automotive diagnostic tool/code reader for today's car owners. iPhone iOS, iPad, Android can be downloaded for free without any additional subscription fees.
- ADVANCED DATA FLOW DISPLAY:AUTOPHIX 3210 PRO Bluetooth code reader allows you to graphically display your vehicle's data flow instead of boring text, including engine coolant temperature, engine RPM, vehicle speed, absolute throttle position, control module voltage, etc. You can view different parameter values corresponding to different times. The advanced data streams provide useful information for entry-level professionals and diyers who can troubleshoot vehicle problems quickly and efficiently.
- 🎉【2024 Upgraded Ver. of AL519/ ML519/ ML619】Autel develops the brand-new AutoLink AL619 as the advanced ver. of Autel ML519, AL519, AL319, MS309. This AL619 OBD2 scanner can scan ABS & SRS systems, and support 10 Modes of OBD II Diagnostics Function on Worldwide Vehicles to read, erase codes and turn off the MIL, ABS, SRS warning lights so that you can better maintain your car when related malfunctions occur and make your vehicle ready for the annual test.
- 🎉【Accurate ABS/ SRS Diagnostics Functions】The ABS/ SRS diagnostic function is used to retrieve and clear codes from the ABS/ SRS systems. It can read and clear DTCs, show definitions of each code, display live data of multiple sensors in the graph to locate fault causes, and assist home mechanics to do the proper repair and clear ABS & Airbag warning lights. Diagnoses ABS/ SRS system codes on most 1996 and newer major vehicle models. Please email 📩 immoautel @ outlook. com 📩 for help.
- 🎉【All 10 Modes of OBD II Diagnostics Function】The OBD II Diagnostics function is a fast-access option that allows you to carry out a quick test on the engine system of OBD II vehicles. Read Codes, Erase Codes, Live Data, Freeze Frame, Retrieving I/M Readiness Status, O2 Monitor Test, On-Board Monitor Test, DTC Lookup, Component Test, Viewing Vehicle Information, Modules Present.
- 🎉【Live Data and Freeze Frame Data】With Live Data functions, Autel AL619 OBD2 diagnostic code reader allows you to view the live PID (Parameter Identification Data) of the vehicle's computer module(s) in text, graph to check the status of various sensors. And Freeze Frame Data enables you to view the vehicle's operating parameters at the moment a DTC is detected. These information will aid the technician by allowing the parameters to be duplicated for diagnostic and repair purposes.
- 🎉【DTC Lookup Feature】Besides showing you the code’s definition while you are reading the diagnostic trouble codes, AL619 features comparably user-friendly DTC Lookup Function which enables you to retrieve the definitions of any error codes from the large database of AL619, saving you from the hassle of wasting time searching definition of every code via Google.
- 2024 Best Choice for ABS Bleeder Scan Tool - Was the brake pedal always slowly sinking down or becoming loose? This abs brake bleeding scan tool will bleed the brake system by cycling the pump and valves to achieve a tight brake pedal. It's the most affordable obd2 scanner with abs auto bleed function you can find. With the clear step by step instruction, even a beginner can use it. Coverage check on FOXWELL official site: Support- Diagnostic Coverage List.
- More Than a Entry Level OBD Scanner, Ideal for Home Mechanics - Based on the NT301 FOXWELL Scanner, NT630 Plus takes OBD diagnostics to the next level by customizing all functions for ABS and SRS systems. This srs abs scanner provides in-depth insights on error code diagnosis, wheel speed sensor live data, airbag circuits and cable connectors monitor, module activation and etc. It's an total game-changer in resolving ABS SRS issues.
- No More Higher End Service than You Needed - One NT630 Plus is enough! This obd2 scanner with abs and srs takes depth diagnosis on Anti-Lock Brake System & Supplemental Restraint System, and also performs daily required resetting services which same priced scanners cannot do. Like Airbag light reset/ SAS(Steering Angle Sensor) adjustment/ Oil light reset service functions. The car scanner will help the part to operate normally after the faults repaired.
- Also can Work like NT301 - The NT630 Plus abs code reader connect to the OBD2 port directly. It will diagnose all obd2 modules instantly, displays the live data, locates bad sensors and I/M readiness status before the annual inspection. Guides you to do the maintenance work, reduces the potential driving risk and keep a peak performance on the road.
- Complicate? Unreadable? - Intuitive LCD display with clear operate instructions, even a beginner can diagnose the car faults with the NT630 Plus. Ergonomic Touch with anti-collision and anti-slip cover design, comfortable for daily car diagnose work. Unique button press sound will provide the overall tactile and visual experience to notice you a task has been completed or a command has been executed.
- 👍【Professional 4 Systems Diagnostics】For DIYers addressing typical concerns like engine, transmission, ABS, and SRS, the TOPDON AD500 vehicle scanner provides specialized diagnostic solutions. It effortlessly interprets and eliminates fault codes and scrutinizes data streams, ensuring the prompt detection of issues.
- 👍【6 Reset Functions】The AD500 car diagnostic tool offers essential features like Oil Reset, Throttle Adaptation, SAS/TPMS/BMS/EPB Reset. Easily reset oil change indicators, fine-tune throttle response, and recalibrate steering angle sensors for optimal vehicle performance and maintenance convenience.
- 👍【Works Easier with AD500】The AD500 scanner combines a 5” touchscreen with buttons for easier and seamless operation. Elevate your diagnostic experience with DTC Lookup, Diagnostic data record, and printing diagnostic reports via email. Stay up to date with lifetime free upgrades via Wi-Fi, ensuring your tool is always equipped with the latest features.
- 👍【Fast Diagnostics, Instant Support】With AutoVIN, instantly obtain crucial vehicle details for expedited diagnostic processes. The AD500 code reader not only facilitates data stream recording for later review but also acts as a battery voltage monitor, providing valuable insights into your vehicle's battery health. If you encounter any diagnostic hurdles, share feedback with TOPDON for prompt professional support.
- 👍【Upgraded ArtiDiag500 for Peak Performance】Experience enhanced performance with the upgraded AD500 diagnostic tool, boasting a 4-core 1.5GHz CPU, 2GB RAM + 32GB ROM, and seamless operation with Android 11.0. Enjoy extended battery life with its 3350mAh capacity. Plus, benefit from TOPDON's 1-year quality backup for added peace of mind.
- [ABS & SRS Scanner with Active Test] The ABS/ SRS diagnostic tool Read & clear DTCs, displays live data in a graph to locate the cause of faults and assists the home mechanic with repairs and clearing ABS and airbag warning lights. Active test sensors, valves or solenoids etc. and tracks any threats in real time. It is invaluable to have a diagnostic tool with Active Test feature that you will never find on similar ABS/ SRS scanners.
- 【3 HOP Reset Services 】Easy to set up 3 regular reset services for Oil Light, Battery Management System, and Steering Angle Position. With this obd2 scanner, you can reset the oil service light and reset pre-programmed mileage intervals for energy efficiency; adjust or reset the steering angle position to keep steering aligned; and clear the original low battery fault information. No need to leave home for shop-quality car maintenance.
- 【All OBD2 Test Modes 】 This ABS & SRS scan tool is also a full featured obd2 code reader, allowing a quick test of the engine system of OBD II vehicles, can Read/Clear engine light codes, Live Data, Freeze Frame, Retrieving I/M Readiness Status, O2 Monitor Test, On-Board Monitor Test, Evap Test, Read Vehicle Information, and help pass smog test for most post-1996 OBD2/CAN vehicles.
- [DTC LookUp Library] Can't read the code? Go to the DTC LookUp Library. The Topdon AL600 OBD2 scanner offers a wealth of code definitions so you don't have to look them up in a list or database, and the HELP function takes you to diagnostic tips for possible fixes, saving time searching for repair materials online. No other scan tool or code reader under $100 offers this level of assistance.
- [User-Oriented] You'll love the feel of this automotive scanner, with black rubber grips all around the outer edges for durability and to withstand accidental drops. With its easy access menu, you can operate all functions in minutes with just a few button presses. The 3-color LEDs give you a intuitive indication of the OBD2 test results in a second. 3 shortcut keys, one key to read/clear DTCs and a one-touch smoke status check make it easy to use even for beginners.
- [Transform Your Car Care Experience] - With BLCKTEC, instantly become your own professional mechanic. Effortlessly read and clear your car’s trouble codes and check engine light, ensuring your vehicle stays in top condition.
- [Empower Yourself with Comprehensive Diagnostics] - Unlock the full potential of your vehicle with the BLCKTEC 430. Access detailed diagnostics previously exclusive to professional mechanics’ OBD2 scan tools, including ABS, Airbag, SRS, TPMS codes, and beyond, right at your fingertips.
- [Drive with Confidence] - The BLCKTEC 430 is more than just a car code reader; it's your personal vehicle health advisor. Receive tailored repair reports with potential causes and verified solutions for your specific make and model, guiding you to the right fix every time.
- [Seamless Connectivity, Ultimate Convenience] - Experience the freedom of wireless diagnostics with this portable car scanner. Easily connect via Bluetooth to our intuitive sensor, and enjoy all the functionalities of high-end scan tools without the clutter of wires, directly from your smartphone or tablet.
- [DIY Repairs Made Easy] - Navigate car maintenance with ease using our premium app. Access a vast library of easy-to-follow repair videos, guiding you through each step of the repair process, compatible with both iOS & Android devices.
- 【Great Ideal For Every Car Owner】Prefect choice for your father, husband, brother or boyfriend. EVERY CAR OWNER WILL NEED IT! It comes with h-igh-quality host with a strong box. Get LAUNCH CRP123 Elite car diagnostic scanner and give your lover a surprise!
- 【 Read & Clear/Reset Engine/ABS/SRS/Transmission Diagnostic Scan Tool 】LAUNCH CRP123 OBD2 Scanner can test Engine, Transmission, ABS and Airbag four systems, also reads and resets code, displays data stream graphic, stores and playbacks dynamic data stream,helps to quick analysis and diagnosis.
- 【 Error Fault Code Reader】Except the full 10 modes OBD2 diagnostic functions like, retrieving I/M readiness, Freeze Frame Data, Read Dynamic Data stream and V-ehicle Information, O2 Sensor Test, EVAP Test of F-uel Tank System (Mode 8) and Advanced On-board Monitoring (Mode 6), launch crp123 obd2 scanner can not only reveal what error codes your car is producing, but also erase your v-ehicle’s check engine light after problem fixed, the DTC help and explanation also tell you the exact problem.
- 【 Live Data Graphing + Read/Record/Playback Data stream + Print diagnostic data 】Live Data Graphing,more intuitive to know your vehicle’s problem.Large size Color Screen ;Print Function:Print the diagnose result easily; with user manual and register & update tutorial video uploaded in the link by us,you can Look up it anytime by ONE-CLICK.
- 【 Find Your Vehicles Here】Launch CRP123 obd2 scanner Supports mainstream vehicles on the world,fit for ACURA VW AUDI AUST FORD BENZ BMW CHRYSLER FIAT GM HOLDEN HONDA HYUNDAI INFINITI JAGUAR ISUZU KIA LANDROVER LEXUS MAZDA MITSUBISHI NISSAN OPEL PORSCHE SAAB SEAT SKODA SMART MERCEDES SPRINTER SUBARU SUZUKI SCION TOYOTA USA FORD VOLVO PEUGEOT CITROEN RENAULT EUROFORD.Etc.
- ABS/SRS OBD2 Scanner > Enjoy this ABS OBD2 code reader to reveal exact issues underlying in your brake, airbag, and engine systems, test individual ABS/SRS sensors, valves, or solenoids to quickly locate malfunctions (compatible with GM, Nissan, Fiat, Benz, Volvo, Land Rover, BMW, USA Ford, please reach us for details.), making sure critical safety systems work in perfect harmony together against accidents to be safe than sorry. NOTE: Only support upgrade on windows.
- 3 Most Needed Service Functions > This OBD2 scanner guides you through step by step procedures to reset oil service light and programmed mileage intervals for engine efficiency (Oil Reset); to calibrate steering wheel position for vehicle’s traveling in a straight line (SAS Reset); to clear the original low battery fault information against coming battery failures or damage (BMS Reset); saving your needless visits to mechanics. NOTE: Not suitable for all models, please reach us for compatibility.
- Full OBD2 Diagnostics > Say goodbye to the hassle of manual check-ups via this srs code reader. Quickly correct Check Engine Light warning on most OBD2/CAN compatible vehicles. Easily access to your smog status with one simple click I/M Readiness; and being filled with features for live data readings, freeze frame data, plus EVAP system, onboard monitor test means this scan tool checks all daily car care boxes.
- Work Easier > Red-Yellow-Green LEDs in this OBD2 scanner quickly show the overall DTC status without toggling through menu selections. HELP hotkey takes you directly to detailed descriptions/tips. Read/Erase DTC, I/M readiness shortcuts are added for optimized operation, along with DTC Lookup library for interpreting codes, designing the SRS OBD2 code reader a pleasure to use right out of the package even for beginners.
- Helpful Service > Get instant, free lifetime access to the most recent updates to add new car models and troubleshooting bugs making the OBD2 scanner a long-term investment for any home mechanics. The extended 1 years of quality assurance sweetens the worry-free deal even further. Multilingual Menu: EN, FR, ES, DE, IT, RU, PT, and JP. NOTE: Only support upgrade on windows.
- 💻Note: (About UPDATE) ANCEL FX2000 car scanner diasgnostic tool can be used directly as it comes with existed software, You don't need to register or update beforethe first use. It's recommended to update your scanner only when it fails to work on your car, or it's slow to load all menus or if you need newer software version. 📢Software update supports WIN XP, 7, 8, 10 operation systems only., but not for Mac and ios system.
- 🔧【PLUG AND PLAY - EASY TO USE】 : ANCEL FX2000 car scanner only takes 3 steps to connect to the car for diagnosis without cumbersome operations. The latest FX2000 scan tool is equipped with a one-key diagnosis function, which can automatically identify the model and year of your car, and automatically diagnose the car. Even beginners can use it to read the data and find out what the fault codes mean.
- 🚗【FULL OBD-LEVEL DIAGNOSTICS TOOL】: Quickly determines the cause of engine system faults, reads current, permanent and pending codes. After the repair, clears the codes and turns off the warning light. In addition, the FX2000 engine code reader also displays important OBD II advanced data such as fuel, live data and other manufacturer-specific parameters in real time to ensure that the engine ECU is operating correctly and safely, saving vehicle owners a lot of time and money in maintenance.
- 🚙【TRANSMISSION FAULT DIAGNOSTIC TOOL】: Some noises come from the transmission? Ancel obd2 scanner will read fault codes, display live transmission system data (fluid temperature, fluid pump, clutch actuation, pressure, etc.), and ensures transmission performance is optimal for vehicle speed and load. It provides detailed TCM data of the vehicle, so you can quickly and accurately find existing or potential problems.
- 🚐【FIND OUT SRS WRONG】: ANCEL FX2000 automotive scanner is able to read and clear fault codes in the SRS (airbag) and turn off the warning light to make sure the system is working correctly and safely. This odb2 scanner also displays a live graphical data stream of the supplemental restraint system (air bag), which allows you to analyze and verify that the air bag system is working properly.
Last update on 2024-04-25 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
